Cone & Thread type Adapters

UJB-HPXHP Series Valves&Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:UJB-14.2HPX6.35HP-N28.5-CN Size： 14.2mm × 6.35mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：250　Min Temperature(℃)：-40 Connection Type： Cone & Thread Type,Other Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Cone & Thread type Adapters

UJB-HPXHP Series Valves&Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:UJB-14.2HPX9.52HP-N28.5-CN Size： 14.2mm × 9.52mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：250　Min Temperature(℃)：-40 Connection Type： Cone & Thread Type,Other Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Cone & Thread type Adapters

UJN-HPXHP Series Valves&Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:UJN-14.2HPX6.35HP-N28.5 Size： 14.2mm × 6.35mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：250　Min Temperature(℃)：-40 Connection Type： Cone & Thread Type,Other Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Automatic Globe Type Stop Valves

M3R4-7100M Series Valves&Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:M3R4-7100M-14.2-MG-N28.5-CN Size： 14.2mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：50　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Detail Inquire

Automatic Globe Type Stop Valves

C160-UH-7100C Series Valves&Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:C160-UH-7100C-14.2-40-N28.5-CN Size： 14.2mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Automatic Globe Type Stop Valves

M3R4-7100M Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:M3R4-7100M-6.35-MG-N28.5-CN Size： 6.35mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：50　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Detail Inquire

Automatic Globe Type Stop Valves

M3R4-7100M Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:M3R4-7100M-9.52-MG-N28.5-CN Size： 9.52mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：50　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Detail Inquire

Check Valves

UCL-7100 Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:UCL-7100-14.2-40-N28.5-CN Size： 14.2mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Automatic Globe Type Stop Valves

C160-ULH-7100C Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:C160-ULH-7100C-14.2-40-XM19-CN Size： 14.2mm

Material：Stainless Steel (XM-19) Max Pressure (MPa)：99.9 Max Temperature(℃)：50　Min Temperature(℃)：-253 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

CAD data：

View Detail Inquire

CAD Data：あり

Automatic Globe Type Needle Valves

E32M2R2-7100CW Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:E32M2R2-7100CW-6.35-※-N28.5-CN Size： 6.35mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-253 Connection Type： Other,Cone & Thread Type Feature： Minute Adjustments Possible,High Pressure Gas Certified

View Detail Inquire

Automatic Globe Type Needle Valves

E32M2R2-7100CW Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:E32M2R2-7100CW-9.52-※-N28.5-CN Size： 9.52mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-253 Connection Type： Other,Cone & Thread Type Feature： Minute Adjustments Possible,High Pressure Gas Certified

View Detail Inquire

Automatic Globe Type Needle Valves

E32M2R2-7100CW Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:E32M2R2-7100CW-14.2-※-N28.5-CN Size： 14.2mm

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-253 Connection Type： Other,Cone & Thread Type Feature： Minute Adjustments Possible,High Pressure Gas Certified

View Detail Inquire

Manual Globe Type Stop Valves

ULH-7100C-XM19 Series Valves & Fittings for Ultra High-Pressure Hydrogen Gas（Coned-and threaded Connection High-Pressure Type） Product No.:ULH-7100C-6.35-XM19-*** Size： 6.35mm

Material：Stainless Steel (XM-19) Max Pressure (MPa)：99.9 Max Temperature(℃)：50　Min Temperature(℃)：-253 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Detail Inquire

Automatic Globe Type Needle Valves

E32M3R4-7100-MG Series Representative Product No.：E32M3R4-7100-6.35-※-MG-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-10 Connection Type： Other,Cone & Thread Type Feature： Minute Adjustments Possible,High Pressure Gas Certified

View Series Detail Inquire

Automatic Globe Type Needle Valves

E32M2R2-7100W Series Representative Product No.：E32M2R2-7100W-14.2-40-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-10 Connection Type： Other,Cone & Thread Type Feature： Minute Adjustments Possible,High Pressure Gas Certified

View Series Detail Inquire

Automatic Globe Type Stop Valves

C160-UH-7100 Series Representative Product No.：C160-UH-7100-14.2-40-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-10 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Series Detail Inquire

Manual Globe Type Needle Valves

UH-7100L Series Representative Product No.：UH-7100L-6.35-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Series Detail Inquire

Check Valves

UCL-7100 Series Representative Product No.：UCL-7100-6.35-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Series Detail Inquire

Filters

UFL-7100 Series Representative Product No.：UFL-7100-6.35-2-N28.5-CN

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type Feature： High Pressure Gas Certified

View Series Detail Inquire

Manual Angle Stop Valves

UH-8100 Series Representative Product No.：UH-8100-14.2-40-N28.5

Material：Stainless Steel (SUS316 Ni28.5%) Max Pressure (MPa)：99.9 Max Temperature(℃)：85　Min Temperature(℃)：-40 Connection Type： Other,Cone & Thread Type,Screw

View Series Detail Inquire
